AVLink JX1700U plug-and-play 4K webcam specially designed for live streaming. This Ultra-HD webcam 4K@30fps, 84degree field of view, with USB3.0 and HDMI connection, suitable for any Mac or Windows or PC computers.
| Model | JX1700U |
|---|---|
| Video Output | 4K@15fps |
| Port | HDMI, USB 3.0, USB2.0 |
| Color | Dark |
4K USB Webcams AutoFocus PTZ Camera with Dual Microphones Wide Angle Lens, Cheap China Price, send inquiry to aliceavlink@gmail.com now!
| Camera | |||
| Video CMOS Sensor | 1/2.5”, CMOS, Effective Pixel: 8M | ||
| Scanning Mode | Progressive | ||
| Lens Mount | M12 | ||
| Lens | Focus: f=3.5mm, FOV: 84° | ||
| Autofocus | Support | ||
| Min Lux | 0.05 lux @ (F1.8, AGC ON) | ||
| Shutter Speed | 1/30s to 1/10000s | ||
| White Balance | Auto, Indoor, Outdoor, One-Push, Manual | ||
| Camera bracket | bracket with damper | ||
| Digital Noise Reduction | 2D,3D digital noise reduction | ||
| Backlight Compensation | Support | ||
| USB Features | |||
| Operate System | Windows® 7 (1080p and under only), Windows 8.1, Windows 10 or higher
macOS™ 10.10 or higher Google™ Chromebook™ Version 29.0.1547.70 or higher Linux |
||
| 2.4 GHz Intel® Core 2 Duo processor or higher
2 GB RAM or more USB 2.0 port (USB 3.0 required for 4K) |
|||
| Color System / Compression | H.265 / H.264 / MJPEG | ||
| Video Format | 4k@30fps/25fps, 1080p@60fps/50fps/30fps/25fps, 720p@60fps/50fps/30fps/25fps, 960x540p@60fps/50fps/30fps/25fps, 640x360p@60fps/50fps/30fps/25fps | ||
| USB Video Communication Protocol | UVC 1.0 ~ UVC 1.5 | ||
| UVC PTZ | Support(EPTZ) | ||
| Input/Output Interface | |||
| USB Interface | 1xUSB 3.0: Type B, famale | ||
| HDMI Interface | 1xHDMI: Version 1.3 | ||
| Audio Interface | 1x 3.5mm Audio Jack: Line In | ||
| General specification | |||
| Input Voltage | 5V (USB power supply) | ||
| Current Consumption | 200mA | ||
| Operating Temperature | -10°C ~ 40°C (14°F ~ 104°F) | ||
| Storage Temperature | -40°C ~ 60°C (-40°F ~ 140°F) | ||
| Power Consumption | 1w | ||
| Size | 194mm x 34mm x 42mm (without bracket) | ||
| Net Weight | 93g | ||
| MTBF | 30000h | ||
JX1700U 4K Ultra HD Webcam With Autofocus Specification
